CM4.80

Assets:

  • Quiet running with less vibrations due to a specially designed flywheel.
  • Seawater resistant cast exhaust bend, providing a long and efficient service life.
  • Cupronickel heat exchanger resistance to corrosion.
  • Air inlet silencer.
  • Fitted with electric fuel lift pump.
  • Based on a Hyundai industrial engine, proven world-wide and with an equally world-wide support.
  • Air intake with noise reducing properties.
  • Complies with RCD I regulations.
Basic Engine Hyundai
Cylinders 4 In Line
Cylinder Capacity 2.607 cm³
Power 59 kW / 80 hp
Max. Engine Speed 4.000 rpm
Max. Torque 175 Nm
Aspiration Natural
Alternator 110 A / 12 V (Bosch / SEG)
Cooling System Intercooling, With Heat Exchanger
Flexible Engine Mounts CM Type 7
Calorifier Connection Standard
Exhaust Diameter ø76 mm
Electronic Protection 10 A Circuit Breaker
Stop Solenoid Energized To Run
Max. Installation Angle 15° (Backwards)
Weight 235 kg

Recommended Components
